With a full line for virtually every wire size and combination, the WingTwist Wire connector offers a great combination of performance and value. The contoured wing design of the WingTwist provides maximum torque for a variety of electrical applications while the copolymer shell and live-action spring expand for smooth, progressive tightening providing dependable connections. With a tough, flame-retardant shell that withstands environmental extremes, and a long, deep skirt to provide maximum dielectric protection to prevent flash-over and turned-back strands, the WingTwist Wire connector brings comfort and performance at a price that is right.
Use to connect and insulate 2 or more copper wires together inside an approved electrical box
For use with #22 to #10 AWG copper conductors - do not use on aluminum
Minimum wire range: two #20 AWG, maximum wire range: three #10 AWG
Expanding square-wire steel springs creates secure connections on a wide range of wire combinations
Wide, deep skirt opening accommodates a variety of wire combinations, while providing maximum insulation
Tough UL 94V-2 listed flame retardant shell rated to 221 F or 105 C, UL Listed E5238, CSA Certified, rated for 600-Volt, 1,000-Volt in lighting fixtures and signs
