The Spee-D® Channel Drain Bottom Outlet Assembly features a 2 foot channel with a prefastened grate to cut down installation time. Bottom outlet connects to 3 inch and 4 inch sewer and drain fittings. Channel is made of polyvinyl chloride and connects with a coupling; grate is made of galvanized steel. The Spee-D Channel, part of the NDS Profile Channel series, is ideal for draining moderate flows from driveways, patios, pool areas, courtyards, and walkways with an open surface area of 15.5 sq. inch/ft., 47 GPM/ft. flow rate, and is ADA compliant. Channel drains, also called trench drains, are long, narrow drains and as part of a complete drainage system, collect water from surrounding surfaces and direct it away to drain pipe. The water is carried to a discharge point downstream such as a pop-up emitter, or to percolate into the ground with a dry well or infiltration trench. NDS channel and trench drains are designed for durability, drainage, and performance, and are a proven alternative to traditional concrete drains. NDS offers free tools such as the Home Drainage Center, Calculators, and NDS Stormwater Drainage mobile app to help make your project a success. Founded in 1972, NDS is the preferred choice of professionals and the leader in stormwater management solutions with proven products, tools, and support to help you get the job done right."
Channel drain and grate come preassembled for a faster install
Bottom outlet is integrated into the channel drain
Bottom outlet connects to 3 inch and 4 inch sewer and drain fittings
The 2 foot Spee-D Channel Drain features a built-in bottom outlet and prefastened grate to capture and convey water to drain pipe
Works with the Spee-D Channel Drain, part of the NDS Profile Channel series, to capture moderate flows from driveways, concrete and paver patios, pool areas, courtyards, and walkways to prevent slippery mildew, concrete staining, and costly structural damage
Use with the Spee-D Channel Drainage system to collect and direct water to drain pipes for proper release downstream
Create a water-tight connection using solvent-weld PVC glue
Spee-D Channel with fabricated grate and bottom outlet measures 4 inch wide and 2 foot long, Spee-D Channel made of polyvinyl chloride (PVC) using a combination of virgin and recycled content treated with UV inhibitors to prevent fading and cracking
Comes with one 2 foot Spee-D Channel Drain with integrated bottom outlet and prefastened galvanized steel drain grate
