HDPE Plastic Driveway Trench Drain System: This driveway trench drain provides an effective collection and drainage of water; Made of durable HDPE plastic, it works efficiently and has a long service time; With the interlocking connection design, you can install it easily; The drain is one meter long each; It can be connected together to fit your need; Rated for B125, it is an ideal choice for your garage; Also, it is suitable for the garden, pool, walkway, courtyard, and other outdoor places;; [Package Content] 6 x Trench Drains; 6 x Plastic Grates; 6 x End Caps
HDPE Plastic Driveway Trench Drain System: Dimensions of each channel: 5.1 W x 3.1 H x 39.4 L IN; The load capacity is B125
It offers six drains featuring built-in bottom outlets, accompanied by six plastic grates and six end caps
Easily installed manually without screws or bolts, it allows for easy detachment
Low-profile Drain System: Dimensions of each channel: 5.1" W x 3.1" H x 39.4" L; Commercial water drainage systems allow safe and efficient drainage for grassed areas, gardens, farms, patio areas, pool sides, office buildings, driveways, or factory interiors; The anti-flotation design prevents floating and doesn’t require staking when setting in concrete;
Easy & Quick Installation: You can connect these trench drains together for extra length; The interlocking design connects the drains tightly with no potential leak of water; Detachable grate can be manually installed and detached easily, needs no screws or bolts; It also provides a convenient way to clean the drain if it is bunged up;
Various Outlet Connections: Each trench drain provides a bottom outlet with multiple sizes(48mm/ 78mm / 96mm), and you can choose the size you need; No outlet connector is required because it is already built-in; thus, the pipe can be connected directly;
Durability & High Performance: Sturdy HDPE plastic creates a hard and durable structure; The load capacity is B125; The HDPE plastic provides a smooth interior surface, which allows faster water intake;
Complete Packing List: This trench drain kit comes with six drains with built-in bottom outlets, six plastic grates, and six end caps; Plus, the outlet connector is already built-in; All the accessories that you may need are included;
Specification: Model: PSG100*45*6M; Material: HDPE Plastic; Color: Black; Load Rate: B125; Amount: 6 Packs; External Item Dimensions: 5.7 x 3.1 x 39.4 inch/ 14.5 x 8 x 100 cm; Internal Item Dimensions: 3.9 x 1.8 x 39.4 inch/ 10 x 4.5 x 100 cm; Diameter of Drain Hole: 48 mm/ 78 mm/ 96 mm; Item Weight Each: 2.48 kg/ 5.5lbs; Maximum Working Temperature: 120 degrees Celsius/ 248 degrees Fahrenheit; Minimum Working Temperature: -40 degrees Celsius/ -40 degrees Fahrenheit
