Triangular Base Under Hoist Jack Stand, Lifting for Car Maintenance Made Simpler: The support capacity of the underhoist support stand is 3/4 ton/1653.5 lbs; The slender yet sturdy and durable support rod design provides the advantage of lightweight and easy operation at close range while being resistant to bending or deformation; It is a helpful tool for inspecting the underside of vehicles and performing professional exhaust repairs, shock absorber replacements, and other vehicle component maintenance tasks;; [Package Content] 1 x Underhoist Support Stand; 1 x 51106 Bearing; 2 x M8×15 Countersunk Bolts; 2 x M14×65 Bolts; 2 x M14 Nuts; 8 x M8×20 Bolts; 8 x M8 Nuts; 2 x 3" Nylon Wheels; 1 x 112×96mm Cotter Pin (with Chain); 1 x User Manual
1653.5 lbs Impressive Load Capacity: This underhoist support stand equipped with wheels is lightweight at only 23.6 lbs / 10.7 kg but can support a remarkable 1653.5 lbs / 0.75 t; The sturdy tubular steel frame helps prevent deformation or twisting; At least 2 stands are required for use and can support most small cars and similar vehicles;
Dual Quick Height Adjustment: The holes on the main post of the jack stand are used to lock in the primary height levels, and the threaded rod assists in adjusting the height; The spin handle incorporates a thrust bearing, making it easy to raise and lower, even under the extreme pressures of a heavy load; The height adjustment range is 38.4" - 74.8" / 975 - 1900 mm, catering to the bottom clearance requirements during most maintenance tasks;
Safety and Stability: A thickened 0.2" / 6 mm circular base and sturdy 0.1" / 3 mm triangular gussets enhance load stability, while the U-shaped tray with rubber padding provides secure, non-slip support without causing damage; This design of our hoist stand ensures a firm and stable hold, preventing the vehicle from wobbling;
Self-Locking Feature for Easy Operation: The threaded screw rod provides a self-locking function to prevent the stand from lowering without assistance; Adjusting the under hoist jack stand under the vehicle is also very safe; The rubber handle provides a comfortable grip;
Versatile Applications: The screw jack provides partial support for positioning vehicle components during installation and removal processes; It provides technicians with added height assistance when working on components such as transmissions, CV joints, radiators, drive shafts, exhaust systems, and catalytic converters, among others;
Specification: Item Model Number: SJS-10; Load Capacity: 1653.5 lbs / 0.75 t; Max; Height: 74.8" / 1900 mm; Min; Height: 38.4" / 975 mm; Main Material: Q235B; Chassis Thickness: Round Base: 0.2" / 6 mm, Triangle Iron Piece: 0.1" / 3 mm; Screw Length: 9.8" / 250 mm; Handle Length: 14.2" / 360 mm; Product Weight: 23.6 lbs / 10.7 kg; Product Dimensions: 14.2" x 14.2" x 39.4" / 360 x 360 x 1000 mm
