This waste and overflow kit comes complete with a pop up drain, overflow cover and extended tubes that are made longer to accommodate center drains and larger bath tubs. A perfect solution for freestanding and clawfoot bathtubs. This entire drain kit comes with a lush oil rubbed bronze finish and is made with 17 gauge solid brass. Although this drain kit was made with copper bath tubs in mind, they can also be used with any other type of tub such as porcelain, stone, acrylic, cast iron, and more.
Waste and overflow kit in oil rubbed bronze
Overall dimensions: 22.5-in x 28.5-in
Drain flange dimension: 2.75-in
Pop up top dimension: 2-in
Bottom drain tube length: 18-in (adjustable)
Drain tube width: 1.5-in
Overflow cover width: 3.25-in
The brass tubing must be cut to the correct length
The bottom tube is made longer to accommodate center drains and larger bath tubs
